Zoom H6 Multi Track Recorder

RECORDING MEDIA

SD Card:

16MB to 2GB

SDHC Card:

4GB to 32GB

SDXC Card:

64GB to 128GB

INPUTS

XYH-6 X/Y mic:

Mic type: Unidirectional

Sensitivity: -41 dB, 1 kHz at 1 Pa

Input gain: -∞ to 46.5 dB

Max sound pressure input: 136 dB SPL

XYH-6 MIC/LINE IN:

Connector: 1/8" stereo mini jack

Input level: - ∞ to 46.5 dB

Input impedance: 2 k Ω

Plug-in power: 2.5V supported

INPUTS 1 to 4:

MicConnectors: XLR / TRS combo jacks

(XLR: Pin 2 hot / TRS: Tip hot)

MicInput gain: (PAD OFF) -∞ to 55.5 dB

MicInput gain: (PAD ON) -∞ to 35.5 dB

MicInput impedance: 1.8kΩ or more

MicMax input level: +22 dBu (PAD ON)

MicPhantom power: +12V /+24V /+48V

(Phantom power can be turned on/off independently for Inputs 1 - 4)

MicEquivalent Input Noise (EIN): -120 dBu or less

OUTPUTS

LINE OUT:

Jack type: 1/8" stereo mini jack

Rated Output Level: -10 dBu when output load impedance is 10k Ω or more

PHONE OUT:

Jack type: 1/8" stereo mini jack

Output Level: 20 mW +20 mW into 32 Ω load

Built-in speaker:

400mw 8 Ω mono speaker

RECORDING FORMATS

WAV:

Sampling frequency: 44.1/48/96 kHz

Bit rate: 16/24

(Mono/Stereo, BWF-compliant)

Maximum simultaneous recording tracks: 8 (L/R + INPUT 1 to 4 + L/R backup)

(Backup recording: -12dB lower than set L/R input gain

MP3:

Sampling frequency: 44.1kHz

Bit Rate: 48/56/64/80/96/112/128/160/192/224/256/320kbps

Maximum simultaneous recording tracks: 2

DISPLAY

LCD Screen:

2.0-inch full color LCD (320 x 240 pixels)

USB

Mass Storage Class operation:

Class: USB2.0 High Speed

Audio Interface operation: Multi-track mode::

Class: USB2.0 High Speed

Inputs / Outputs: 6 / 2

Sampling frequency: 44.1/48kHz/96kHz

Bit rate: 16/24 bit

USB bus powered operation possible

BATTERY LIFE

Battery life (with alkaline battery, continuous recording) Over 20 hours
